4.4.2. TR split-core current sensors
4.4.2.1. Range
TR-10 TR-16 TR-24 TR-36
Cable
passage
diameter
ø10mm ø24mm
I nominal
Maximum l
Reference
4.4.2.2. Dimensions
PA
L
Ø W
C
B
H
Dimensions in/mm
TR-10 TR-16 TR-24 TR-36
LxHxD
0.98 x 1.54 x 2.79
1.18 x 1.65 x 2.91
1.77 x 1.73 x 3.74
2.24 x 1.65 x 4.37
W
0.39
10
0.63
0.94
24
1.42
A
2.28
2.40
2.83
72
3.23
B
0.57
14.5
0.75
0.87
22
0.87
22
C
1.02
1.22
31
1.34
34
1.59
40.5
