6. DIRIS B-30 CONNECTION
6.1. Description of the DIRIS B-30 terminals
4x current sensor
inputs
RS485
7 mm
0.14 mm
2
-> 1.5 mm
2
solid
0.14 mm
2
-> 1.5 mm
2
stranded
Optional modules
Voltage inputs
DIRIS D
display
Auxiliary power
supply
USB
10 mm
0.2 mm
2
-> 2.5 mm
2
solid
2
-> 1.5 mm
2
10 mm
0.2 mm
2
-> 2.5 mm
2
solid
2
-> 1.5 mm
2
Current sensor
inputs
