Number of modules 8 9 10 11 12 13
Power
(N+1 redundant)
kW 350+50 400+50 450+50 500+50 550+50 600+50
kVA 350+50 400+50 450+50 500+50 550+50 600+50
Input
Input mains voltage 3ph + N 340 V to 480 V (+20/-15%) up to -40% @ 70% of nominal load
Input mains frequency Hz 40 to 70
Input power factor ≥ 0.99
(2)
Total harmonic input current
distortion (THDi)
≤ 3% (@: Pn, Resistive load, Mains THDv ≤ 1%)
Output
Output voltage
(three phase + neutral)
V 3Ph+N 380/400/415 V ±1%
(3)
Frequency Hz 50-60 Hz (selectable) ±0.01%
Total output voltage distortion
(THDv)
% ≤ 1% (Ph/Ph); ≤ 2% (Ph/N) (@: Pn, Resistive load)
Overload
(4)
10 min kW 500 562.5 625 687.5 750 750
1 min kW 600 675 750 825 900 900
Crest Factor ≥ 2.7
Bypass
Bypass input voltage V Nominal output voltage ±15% (±20% if GENSET is used)
Bypass input frequency Hz 50/60 +/-2% selectable (±8% if GENSET is used)
Stored energy mode of operation
Battery voltage range V From+/-180
(5)
up to+/-330
(6)
(18+18 to 24+24 VRLA battery blocks)
(7)
Environmental
Operating temperature °C 0-40 °C (+15 °C to +30 °C recommended)
Storage temperature °C –25 °C to +55 °C
Relative humidity % 95% condensation-free
Altitude (max) m 1000 (3000 with derating)
Acoustic noise (@ 70% Pn) dBA 59 60 61 62 63 64
Cooling type
Air cooling
Required cooling capacity m
3
/h 4800 5400 6000 6600 7200 7800
Dissipated power (max) W 16880 19730 22200 25220 27740 30920
Dissipated power (max) BTU/h 57600 67330 75750 86060 94660 105510
Dimensions and Weight
Dimensions (W x D x H) mm 1200 x 960 x 1990
"M5-S-650-82
(2x Bypass modules included)"
kg 788 824 860 896 932 968
"M5-S-650-88
(2x Bypass modules included)"
kg 788 824 860 896 932 968
"M5-S-650-88
(3x Bypass modules included)"
kg 812 848 884 920 956 992
UPS module kg 36
Standar
d
Safety EN/IEC 62040-1 - AS 62040-1
EMC EN/IEC 62040-2 - AS 62040-2
Product certification IECEE CB Scheme
Performance EN/IEC 62040-3 - AS 62040-3
Product marks CE - RCM
(8)
- CMIM
(8)
- UKCA
(8)
Protective class Protective Class I
Touch current < 1 mA
Protection level IP20
