System with manual bypass, input, aux. mains and output switches (with or without extra bypass module)
Ethernet network 2 (only for service)
USB connector 1 (only for service)
USB connector 2 (only for service)
Option slot 1
Option slot 2
Backfeed connector / Options
Option slot 3
Power supply fuses
Q3 (Output switch)
Q5 (Manual Bypass
switch)
UPS connections
Q4 (Auxiliary mains
switch)
Q1 (Input mains
switch)
Hot-swap bypass
module 2
Hot-swap bypass
module 3
(extra)
Hot-swap bypass
module 3
(extra)
Hot-swap bypass
module 1
Ethernet network 1 (only for service)
