2.PYLON-AH
(Only for PYLON)
5.Discharge Depth
3.Max Charge (A)
6.Save
OK
Depth of Discharge
For example: if Discharge Depth = 50% & EPS Discharge Depth = 80%.
While grid is connected: Inverter won’t discharge the battery when its SOC is
less than 50%.
In case of blackout: Inverter will work in EPS mode (if EPS mode is enabled)
& keep discharging the battery till battery SOC is less than 20%.
5.Discharge Depth
OK
Discharge Depth
80%
Discharge Depth
EPS 80%
EPS Safety Buffer
20%
2.
Feed-in Limitation
The user can enable “Feed-in Limitation” to limit the max export power to
grid.Reflux Power set is desired max export power to grid. Refer to 4.7.2 for
connection of the system when using Feed-in Limitation function.
2.Feed-in Limitation
OK
1.Feed-in Limitation
OK
Enable
Disable
2.Feed-in Power
OK
***KW
3.Hard Limit Control
OK
Enable
Disable
3.
IV Curve Scan
The user can enable “IV Curve Scan” (MPPT scan) to make inverter to find
the global max power point periodically to deliver max power from a partially
shaded PV array.
The user can input scan period or make inverter to perform a scan right
away.
3.IV Curve Scan
OK
1.Scan Control
OK
Enable
Disable
2.Scan Period
OK
***min(s)
3.Force Scan
OK
4.
Logic Interface
Enable or disable logical interfaces. Please refer to this manual 4.7.2, inverter
logic interface connection for details.
