25
Installation and Operation
3.2.1.5 Battery Settings
The Battery Settings block is under the Battery Test block on the PSX page (See Figure 3.3, page 22). The available settings are as follows:
Rated Battery Life Enter the rated battery life or desired replacement period in years. This is used by the PSX-NL4 to calculate
the Battery End-of-Life alert time. Note: The current time and date MUST be set BEFORE setting the
rated battery life for proper Battery End-of-Life date calculation.
Rated Capacity Enter the battery capacity of the battery connected to the PSX. This rating is used by the PSX-NL4 to approxi-
mate how much capacity is remaining in the battery (if using the current sensor to monitor battery health).
i Note: After setting the battery information, click the "Submit" button for the changes to take effect.
Figure 3.6 - Typical Status Page (top portion)
