Software House PSX-NL4 User Manual

1
Installation and Operation
The following pages cover the installation of the PSX-NL4 Network Communication Accessory.
1.1.1 Mounting the PSX-NL4 Network Communication Accessory
Use the following procedure when mounting an PSX-NL4 Network Communication Accessory to an enclosure.
1. Locate the appropriate mounting holes in the enclosure and snap the four standoffs provided into the holes.
2. Align the board mounting holes (mounting hole locations are indicated in the drawing below) with the standoffs and snap the board
onto the standoffs. Be sure the board is properly oriented before snapping the board onto the standoffs.
NL4
Figure 1.1
Section 1 – Installation
PSX-NL4
