21
Installation and Operation
3.2 Accessing and Programming Connected Devices
When devices are connected to the PSX-NL4, detailed information relating to these devices may be viewed and various pa-
rameters of these devices can be programmed through the PSX-NL4's interface. Note that programming these parameters
changes the operation of the device itself. To access the page for a device, click on the photo of the device in the PSX-NL4
Connected Devices section of the home page. (See bottom of Figure 3.1 page 19).
3.2.1 PSX Power Supplies
The PSX Power Supply page (Figure 3.2) contains the same Site ID, Time, and Date information as the Home page of the
PSX-NL4; below that are five main sections.
3.2.1.1 PSX Device Parameters & History
The section at the top left of the screen will show the available parameters of the PSX Power Supply.
Figure 3.2 - Typical PSX Page (top portion)
To Next Page
