INDEX
Chapter Par. Description Page
1 Introduction 4
2 Ordinary maintenance 4
3 Possible Application 4
4 General precautions 5
4.1 Electrical Safety Rules 6
4.2 Antifire Safety Rules 6
5 Symbols description 6
6 Commands description 7
7 Installation 10
7.1 Connection to the line of user 10
7.2 Electrode installation (MMA) 11
7.3 TIG LIFT installation 12
7.4 MIG/MAG installation 14
7.5 MIG/MAG, FCAW-S installation with SPOOL GUN torch 16
7.6 FCAW-S flux cored wire without gas 17
8 Front panel operation 18
8.1 Electrode setting (MMA) 18
8.2 TIG LIFT setting 19
8.3 MIG/MAG setting 19
8.4 TORCH SWITCH cycle selection 22
8.5 SUBMENU parameters 23
9 SPOOL GUN socket 27
10 Error codes 28
11 Restore factory data 29
12 Warnings 30
12.1 Work environment 30
12.2 Good ventilation 30
12.3 The supply voltage must be correct 30
12.4 Overload of welding current is forbidden 30
12.5 Internal overheating protection 30
13 Troubleshooting 31
14 Technical specifications 32
15 Spare parts list 33
16 Electric scheme 35
