Sol PLUS Series - Page 88

32
Instruction Manual - Technical Section
PLUS 210 C
14. TECHNICAL SPECIFICATIONS / SPECIFICHE TECNICHE
Technical Parameter
Unit
Model
PLUS 210 C
Code
17131
Rated input voltage
VAC
230 ±15% (1-phase)
Frequency
Hz
50 / 60
Fuse
A
T25
Rated input power
KVA
6,4
Rated input current
A
25
Welding current
range
MIG
A
30 - 210
MMA
10 - 200
TIG LIFT
Voltage range
MIG
V
10 - 26
Rated duty cycle ED (40°C)
%
35
Permanent
secondary
current 100%
MIG
A
124
MMA
118
TIG
No-load voltage
V
63 (13,6 with VRD ON)
Stick Electrode possibility
Ø
5
Welding wire diameter
applicable
mm
0.6 - 1.0
Wire spool diameter
mm
200 - 300
Wire feeding speed
m/min
2 - 15
Down slope time
s
0 - 10
Housing protection grade
IP
21S
Insulation grade
F
Standard
EN 60974-1 / EN 60974-10
Noise
db
< 70
Weight
kg
19,5
Size (Width×Height×Length)
mm
220 × 420 × 540
