SolarEdge L20-IB00 - Figure 2 Front View (Without Door) and Rear View of L20 and L30; Table 2 Cabinet Overview

10
L20, L30
Figure 2 Front view (without door) and Rear View of L20 and L30
Table 2 Cabinet overview
(1) LCD panel
(2)
Terminal block for Input, output &
GND
(3) Bypass Switch
(4) Mains Switch
(5) Maintenance switch
(6) Output switch
(7)
Communication panel
(8)
Rear cover
(9)
Terminal block for battery
