SolarEdge L20-IB00 - Table 8 Alarm Information

59
L20, L30
No
Fault
Cord
UPS Alarm Warning
Buzzer
LED
37
094
Bypass SCR short
Beep continuously
Fault LED lit
38
0C5
Beep continuously
Fault LED lit
39
09A
Output CT Reverse
Beep continuously
Fault LED lit
40
09D
Bypass Feedback Fault
Beep continuously
Fault LED lit
Table 8 Alarm Information
No
Alarm
Cord
UPS Alarm Warning
Buzzer
LED
1
103
Battery Over Voltage
Once per second
BATTERY LED blinking
2
104
BAT Low Pre-warning
Once per second
BATTERY LED blinking
3
105
Battery Reverse
Twice per second
BATTERY LED blinking
4
106
Battery EOD
Once per second
BATTERY LED blinking
5
107
Battery Voltage low
Once per second
BATTERY LED blinking
6
108
No Battery
Once per second
BATTERY LED blinking
7
109
Input Phase Reverse
Once per second
INVERTER LED blinking
8
10A
Input N-Line lost
Twice per second
INVERTER LED blinking
9
10B
Mains Freq. Abnormal
Once per 2
seconds
INVERTER LED blinking
10
10C
Mains Volt. Abnormal
Once per 2
seconds
INVERTER LED blinking
11
10D
REC Comm. Error
Once per 2
seconds
INVERTER LED blinking
12
10E
Mains input lost
Once per 2
seconds
