SolarEdge L20-IB00 - Page 67

58
L20, L30
No
Fault
Cord
UPS Alarm Warning
Buzzer
LED
14
019
REC Initializes Fault
Beep continuously
Fault LED lit
15
01D
Unit insert fault
Once per 2 seconds
Fault LED lit
16
063
Once per 2 seconds
Fault LED lit
17
01E
Rectifier Fault
Beep continuously
Fault LED lit
18
041
Inverter Fault
Beep continuously
Fault LED lit
19
044
INV IGBT SHORT
Beep continuously
Fault LED lit
20
047
Inverter relay Short
Beep continuously
Fault LED lit
21
04A
Inverter relay Broken
Beep continuously
Fault LED lit
22
04D
INV par. cable Fault
Twice per second
Fault LED lit
23
051
Output Short Circuit
Once per second
Fault LED blinking
24
054
INV Comm. Fault
Once per 2 seconds
Fault LED blinking
25
057
INV Initializes Fault
Beep continuously
Fault LED lit
26
05A
INV self-test Fault
Beep continuously
Fault LED lit
27
05E
DC Component Fault
Once per 2 seconds
Fault LED lit
28
061
DC bus abnormal
Beep continuously
Fault LED lit
29
064
INV DSP Power Fault
Beep continuously
Fault LED lit
30
067
INV Over Temperature
Twice per second
Fault LED lit
31
068
Load Sharing Fault
Twice per second
Fault LED lit
32
06A
Cabinet mode Fault
Beep continuously
Fault LED lit
33
06B
Fuse Broken
Beep continuously
Fault LED lit
34
081
Par. cable Fault
Twice per second
Fault LED lit
35
091
Bypass SCR Broken
Beep continuously
Fault LED lit
36
0C2
Beep continuously
Fault LED lit
