SolarEdge SE Series User Manual

Creating Logical and Physical Layout using Installation
Information
To display a logical layout, insert the inverter serial number in the new site created in
the monitoring platform. When the communication between the inverter and the
monitoring server is established, the logical layout is displayed.
To display a physical layout, you need to map the locations of the installed power
optimizers. To map the locations, use one of the methods described in the next sections.
Designer
Designer recommends inverter and power optimizer selection per site size and enables
report generation. You can create a project in Designer and export the site design with
the string layout to the monitoring platform.
For more information, refer to
https://www.solaredge.com/products/installer-tools/designer#/.
Mapper Application
Use the Mapper smart phone application to scan the power optimizer
and inverter 2D bar-codes and create a virtual map of a PV site for
enhanced monitoring and easier maintenance.
The Mapper
Simple on-site registration of new systems.
Creating, editing and verifying system physical layout.
Scanning and assigning the power optimizer serial number to the correct module in
the system physical layout.
For detailed information, refer to the Mapper demo movies:
Creating new sites using the Mapper mobile application
Mapping existing sites using the Mapper mobile application





Chapter 5: Activating, Commissioning and Configuring the System 44
Three Phase Inverter with SetApp Configuration PN: SEXXK-XXXXIXXXX

SolarEdge SE Series Specifications

General

Efficiency	Up to 99%
Protection Rating	IP65
Communication	Ethernet, Wi-Fi (optional), RS485
Dimensions	Varies by model
Weight	Varies by model
Rated AC Power	Varies by model
Max. DC Power	Varies by model
Model	SE Series (e.g., SE3000H, SE5000H)
AC Output Power	Varies by model
MPPT Range	Varies by model
Operating Temperature	-25°C to 60°C
Warranty	12 years standard, extendable to 20 or 25 years
