SolarEdge SE Series User Manual

 SE25K SE27.6K SE30K SE33.3K Unit
Applicable to inverters with part
numbers
SEXXK-XXX0IXXXX 
AC output of Inverter:
Gland Cable Diameter
Line wire cross section
PE cross section

19 - 28 mm
4 - 16 mm
2
4 - 16 mm
2
AC output of DC Safety Unit:
Cable diameter of AC gland
Cable diameter of PE gland
Cross section of line wire
Cross section of PE wire

19 - 28 mm (model dependent)
5 -10 mm
4 - 16 mm
2
4 - 16 mm
2
DC Input
(1)
 4 MC4 pairs
DC Input with DC Safety Unit
(2)
Configuration 1: 4 MC4 pairs
Configuration 2:  4 Strings: Gland cable diameter
5 - 10 mm
Wire cross section 2.5 - 16mm
2
Dimensions (HxWxD) 558 x 328 x 273 mm
Dimensions with Safety Unit (HxWxD) 839 x 328 x 300 mm
Weight 32 kg
Weight with Safety Unit 36.5 kg
Operating Temperature Range
(3)
-40 - +60 °C
Operating humidity < 95 %
Cooling Fan (user replaceable) 
Noise < 62 dBA
Protection Rating/ Environmental
category
IP65 
Pollution degree classification (inside/
outside)
2/3 
Mounting bracket Mounting Bracket provided 

(1)
Only MC4 connectors manufactured by Stäubli are approved for use
(2)
Only MC4 connectors manufactured by Stäubli are approved for use
(3)
See Temperature de-rating - Technical Note at:
https://www.solaredge.com/sites/default/files/se-temperature-derating-note.pdf
Technical Specifications - Three Phase Inverters for Europe &APAC for
220/380V, and 230/400V Grids 74
Three Phase Inverter with SetApp Configuration PN: SEXXK-XXXXIXXXX

SolarEdge SE Series Specifications

General

Efficiency	Up to 99%
Protection Rating	IP65
Communication	Ethernet, Wi-Fi (optional), RS485
Dimensions	Varies by model
Weight	Varies by model
Rated AC Power	Varies by model
Max. DC Power	Varies by model
Model	SE Series (e.g., SE3000H, SE5000H)
AC Output Power	Varies by model
MPPT Range	Varies by model
Operating Temperature	-25°C to 60°C
Warranty	12 years standard, extendable to 20 or 25 years
