SolarEdge SE4000H User Manual

NOTE
The symbol appears at grounding points on the SolarEdge equipment. This
symbol is also used in this manual.
NOTE
A SolarEdge inverter may be installed in a site with a generator. SolarEdge
requires installing a physical or electronic interlock, which will signal to the
inverter when the grid has been disconnected. Interlock procurement,
installation, maintenance and support are the responsibility of the installer.
Damage to the inverter due to incorrect interlock installation or use of an
interlock that is incompatible with the SolarEdge system will render the
SolarEdge warranty invalid.
For more information, refer to
https://www.solaredge.com/sites/default/files/se-inverter-
support-of-voltage-sources.pdf.
NOTE
The following warning symbols appear on the inverter warning label:
Risk of electric shock
Risk of electric shock from energy stored in the capacitor. Do not
remove cover until 5 minutes after disconnecting all sources of
supply.
Hot surface – To reduce the risk of burns, do not touch.
EV Charging Single Phase Inverter Guide MAN-01-00583-1.5
8 IMPORTANTSAFETYINSTRUCTIONS

SolarEdge SE4000H Specifications

General

Model	SE4000H
Manufacturer	SolarEdge
AC Output Power	4000 W
Rated AC Power	4000 W
Max. AC Power	4000 VA
AC Voltage	240 V
Max. Input DC Voltage	480 Vdc
Dimensions	26.2 x 15.4 x 8.3 in
Weight	44.1 lbs
Cooling	Natural Convection
Protection Rating	IP65
AC Voltage Range	211-264 V
Frequency	60 Hz
Number of MPP Trackers	1
Protection Degree	IP65
Max. Output Current	16.7 A
MPPT Voltage Range	380 - 480 Vdc
Max. DC Input Current	15 A
Operating Temperature Range	-25°C to 60°C
Maximum Efficiency	99%
Max. Efficiency	99%
