Solaris FLARE - Basic Mode Functions

Solaris Flare / Flare Jr. user manual version 9.1 111215
16
BASIC MODE
In Basic Mode, the fixture can be used as a wash/blinder, generic strobe, or color strobe.
The first modes are the RGB and RGBW modes in 8bit resolution or 16bit resolution.
The RGB modes are designed to automatically adjust the white LEDs according to the RGB mix coming from the
lighting controller.
The RGBW modes are designed to give independent control of all 4 colors.
8 bit control uses one DMX channel for each color, and 16 bit control allows for two DMX channels of control to
give the lighting controller more steps of dimming.
Mode
Channel
DMX values
Preset
Function
RGB
8bit
1
0 - 255
0 - 100
Red Intensity
2
0 - 255
0 - 100
Green Intensity
3
0 - 255
0 - 100
Blue Intensity
RGB
16bit
1
0 - 255
0 - 100
Red Intensity HI Byte
2
0 - 255
0 - 100
Red Intensity LOW Byte
3
0 - 255
0 - 100
Green Intensity HI Byte
4
0 - 255
0 - 100
Green Intensity LOW Byte
5
0 - 255
0 - 100
Blue Intensity HI Byte
6
0 - 255
0 - 100
Blue Intensity LOW Byte
Mode
Channel
DMX values
Preset
Function
RGBW
8bit
1
0 - 255
0 - 100
Red Intensity
2
0 - 255
0 - 100
Green Intensity
3
0 - 255
0 - 100
Blue Intensity
4
0 - 255
0 - 100
White Intensity
RGBW
16bit
1
0 - 255
0 - 100
Red Intensity HI Byte
2
0 - 255
0 - 100
Red Intensity LOW Byte
3
0 - 255
0 - 100
Green Intensity HI Byte
4
0 - 255
0 - 100
Green Intensity LOW Byte
5
0 - 255
0 - 100
Blue Intensity HI Byte
6
0 - 255
0 - 100
Blue Intensity LOW Byte
7
0 - 255
0 - 100
White Intensity HI Byte
8
0 - 255
0 - 100
White Intensity LOW Byte
