Solaris FLARE - Advanced RBGW Strobe DMX Channels

Solaris Flare / Flare Jr. user manual version 9.1 111215
23
RGB PIXEL
MODE 12
26
0 - 255
0 - 100
7 pix Red intensity
27
0 - 255
0 - 100
7 pix Green intensity
28
0 - 255
0 - 100
7 pix Blue intensity
29
0 - 255
0 - 100
8 pix Red intensity
30
0 - 255
0 - 100
8 pix Green intensity
31
0 - 255
0 - 100
8 pix Blue intensity
32
0 - 255
0 - 100
9 pix Red intensity
33
0 - 255
0 - 100
9 pix Green intensity
34
0 - 255
0 - 100
9 pix Blue intensity
35
0 - 255
0 - 100
10 pix Red intensity
36
0 - 255
0 - 100
10 pix Green intensity
37
0 - 255
0 - 100
10 pix Blue intensity
38
0 - 255
0 - 100
11 pix Red intensity
39
0 - 255
0 - 100
11 pix Green intensity
40
0 - 255
0 - 100
11 pix Blue intensity
41
0 - 255
0 - 100
12 pix Red intensity
42
0 - 255
0 - 100
12 pix Green intensity
43
0 - 255
0 - 100
12 pix Blue intensity
ADVANCED RGBW STROBE DMX CHANNELS
FLARE
FLARE Jr.
PIXEL MODE
CHANNEL
DMX VALUE
PERCENT
FUNCTION
PIXEL MODE
FUNCTION
RGBW PIXEL
MODE 1
1
0 - 255
0 - 100
Red Strobe Intensity
RGB PIXEL
MODE 1
Red Strobe Intensity
2
0 - 255
0 - 100
Green Strobe Intensity
Green Strobe Intensity
3
0 - 255
0 - 100
Blue Strobe Intensity
Blue Strobe Intensity
4
0 - 255
0 - 100
White Strobe Intensity
White Strobe Intensity
5
0 - 255
0 - 100
Strobe Intensity
Strobe Intensity
6
0 - 255
0 - 100
Strobe Duration
Strobe Duration
7
0 - 255
0 - 100
Strobe Rate
Strobe Rate
8
0 - 255
0 - 100
Strobe FX
Strobe FX
9
0 - 255
0 - 100
1 pix Red intensity
1 pix Red intensity
10
0 - 255
0 - 100
1 pix Green intensity
1 pix Green intensity
11
0 - 255
0 - 100
1 pix Blue intensity
1 pix Blue intensity
12
0 - 255
0 - 100
1 pix White intensity
1 pix White intensity
RGBW PIXEL
MODE 2V or 2H
13
0 - 255
0 - 100
2 pix Red intensity
RGBW PIXEL
MODE 2V or
2H
2 pix Red intensity
14
0 - 255
0 - 100
2 pix Green intensity
2 pix Green intensity
15
0 - 255
0 - 100
2 pix Blue intensity
2 pix Blue intensity
16
0 - 255
0 - 100
2 pix White intensity
2 pix White intensity
RGBW PIXEL
MODE 3
17
0 - 255
0 - 100
3 pix Red intensity
RGBW PIXEL
MODE 4
3 pix Red intensity
18
0 - 255
0 - 100
3 pix Green intensity
3 pix Green intensity
19
0 - 255
0 - 100
3 pix Blue intensity
3 pix Blue intensity
20
0 - 255
0 - 100
3 pix White intensity
3 pix White intensity
RGBW PIXEL
MODE 4
21
0 - 255
0 - 100
4 pix Red intensity
4 pix Red intensity
22
0 - 255
0 - 100
4 pix Green intensity
4 pix Green intensity
23
0 - 255
0 - 100
4 pix Blue intensity
4 pix Blue intensity
24
0 - 255
0 - 100
4 pix White intensity
4 pix White intensity
