Solaris FLARE - Advanced Modes and Pixel Configuration

Solaris Flare / Flare Jr. user manual version 9.1 111215
19
Strobe Only
Mode
1
0 - 255
0 - 100
Strobe Intensity
2
0 - 255
0 - 100
Strobe Duration
3
0 - 255
0 - 100
Strobe Rate
4
0 - 255
0 - 100
Strobe FX
ADVANCED MODES
This control submenu setup is for advanced users allowing control of both Strobe Color and Strobe
Intensity/Duration/Rate/FX independently of Wash/Blinder background color. This also allows independent
control individual segments of 8 LEDs in the array.
RGB or RGBW control can be selected, plus the desired pixel segments.
The LED segments are comprised of 8 LEDs. There are two segments of 8 LEDs per row. There are 6 rows of
LEDs, for a total of 12 controllable segments. The more segments chosen, the more sets of RGB or RGBW will
follow the Strobe Color and Strobe Control channels.
Choose how many sections (PIXELS) of control after choosing color mode (RGB or RGBW).
