24
6.3 Switching off the inverter
DANGER
■ Even when the DC isolating switch is switched off, the components and connec-
tions of the inverter are still live!
■ After disconnecting the inverter wait at least 5 minutes before opening the device
to permit internal capacitors to discharge.
■ The MC connector (DC input), may only be separated from the inverter if the
DC isolating switch is open. Otherwise, disconnecting the DC feed lines during
operation can result in dangerous arcs.
Procedure
Action Reaction
1. Switch off any external AC isolating
switches/fuses (if present)
The graphics display shows the device status
“No mains”.
The status LED glows orange.
2. Switch off the DC insulation switch The inverter shuts itself off after a few
seconds
6.4 Operating the graphics display
The graphic display on the front of the inverter shows the system dimensions, status
information and the inverter’s malfunction messages. The display allows you to learn the
current device status, access the integrated data logger, and enter various settings for the
inverter. Navigate the various menus using the three buttons under the display.
The display is backlighted to improve readability when lighting is poor. Activate the back-
light by pressing any of the buttons. The backlight remains active for 180 seconds after
the buttons were last used.
To the left of the graphics display there is a status LED indicating the device status, see
9.1 “Status messages and status LED”.
