6.4.2.1 Main menu
The main menu is the starting point for all the submenus and displays, see 6.4.2 “Menu
structure”. Use the arrow keys
and to select a menu. Click to con rm your
selection.
6.4.2.2 Overview
If none of the buttons are pushed for 120 seconds, the display returns automatically to
the Overview menu which shows the three most important values as well as the current
operating status.
Operating parameters Description
19.07.2007 (example) Current date
11:14:49 (example) Momentary time
Pac Momentary effective output
Today Total energy fed into the mains on the current
date and as of the momentary time.
Total Total energy fed into the mains since the
inverter’s commissioning.
Status For the display of the warnings and status
messages, see 9. Operating status.
