SolaX Power X1-Hybrid-5.0-D User Manual

84
85
Setting
Setting
>OverVoltage_L1
0.0V
Grid
>UnderVoltage_L1
0.0V
Grid
>OverVoltage_L2
0.0V
Grid
>Vac 10min Avg
0.0V
Grid
>OverFreq_L1
0.0Hz
Grid
>UnderFreq_L1
0.0Hz
Grid
b) Grid Parameters
Here you can set the protection value of grid voltage and frequency.
The default value is the specified value under the current safety
regulations, and the user cannot change it .
The display content will be displayed according to the requirements
of local laws and regulations, which are constantly increasing. Please
refer to the contents displayed on the inverter screen.
c)Export Control
This feature allows the inverter to control the amount of electricity
output to the grid.
The factory value is the default and can be changed by the user.The
user value set by setup must be less than the maximum.If the user
does not want to supply power to the grid, set it to 0.
User value:
0W
Export Control
d)Meter/CT Settings
The user needs to select the CT or electricity meter to connect the
inverter here.Select the address of the meter. CT does not need to select
the address.
＞Select
Meter
CT/Meter Setting
＞Meter 1Addr:
xxxxxxxx
CT/Meter Setting
e) Self Test (only for CEI 0-21)
The self test function allows users to test the following items. "Full test",
"Ovp(59.S2) test"27. "Uvp (s1) test", "Uvp (27. s2) test", "Ofp (81> .S1) test",
"Ufp (81 <.S1) test", "Ufp (81> .S2) test", "Ufp (81 <.S2) test",
"Ovp10 (59. s1) test".
In the self-test interface, the user can select "all tests" or a single test item for
testing.
Before testing, make sure that the inverter is connected to the grid.
All tests take about 6 minutes. And it will display "Success" and then "Delivery".
For a single test item, it takes about a few seconds or minutes.
Click "Test Report" to view the test results of all items.
ALL Test
Test report
Uvp(27.S1) test
Ft: 51.50Hz Tt:1000ms
Fs: 0.00Hz To: 998ms
F0: 0.00Hz pass
>Ofp2(81>.S2)result
Vt: 264.5V Tt: 300ms
Vs: 0.0V To: 200ms
V0: 0.0V pass
>Ovp2(59.S2)result
Vt: 92.0V Tt: 200ms
Vs: 0.0V To: 196ms
V0: 0.2V pass
>Ofp2(27.S2)result
Vt: 195.5V Tt: 400ms
Vs: 0.0V To: 200ms
V0: 0.0V pass
>Uvp2(27.S1)result
Ft: 50.50Hz Tt: 100ms
Fs: 0.00Hz To: 96ms
F0: 0.2Hz pass
>Ofp2(81>S1)result
Ft: 49.50Hz Tt: 100ms
Fs: 0.00Hz To: 98ms
F0: 0.02Hz pass
>Ufp2(81<.S1)result
Ft: 47.50Hz Tt: 400ms
Fs: 0.00Hz To: 3999ms
F0: 0.02Hz pass
>Ufp2(81<.S2)result
Vt: 253.0V Tt: 600ms
Vs: 0.0V To: 598ms
V0: 0.0V pass
>Ovp10(59.S1)result
