Ø Advance settings
Setting
Setting
Safety Code
Grid Parameters
Advanced
>
1) Safety Code
User can set safety standard according to different countries and grid tied.
There are now several standards to choose from. (There may be changes
in the future, please refer to the screen display.)
OverVoltage_L1
UnderFreq_L1
UnderVoltage_L1
Vac 10min Avg
OverVoltage_L2
OverFreq_L2
UnderVoltage_L2
OverFreq_L1
UnderFreq_L2
Tovp_L1
Tuvp_L1
Tovp_L2
Tofp_L1
Tuvp_L2
Grid Parameters
Tofp_L2
Reconnection Time
Tufp_Fast
Checking Time
OFPL_Setting
W(Gra)
UFPL_Setting
Local Command
Grid Parameters
>OverVoltage_L1
0.0V
Grid Parameters
>UnderVoltage_L1
0.0V
94
95
Advanced settings
1)
2)
3)
4)
5)
6)
7)
8)
9)
10)
11)
12)
13)
14)
15)
16)
17)
18)
19)
20)
21)
22)
23)
Safety Code
Meter/CT Settings
Grid Parameters
Self Test
FVRT Function
GMPPT
Pu Function
Modbus
Export Control
Power Factor
HotStandby Setting
DRM Function
Reset
Power Limit
Main Breaker Limit
Battery Heating
EPS Setting
Charger
External ATS
Parallel Setting
ShutDown
MicroGrid
PV Connection
24)
AS4777 Setting
ExternalGen
25)
>OverFreq_L1
0.0Hz
>UnderFreq_L1
0.0Hz
Tufp_L1
Grid Parameters
Grid Parameters
Grid Parameters
All advanced settings can be set here, such as battery, grid, EPS(Off-grid), etc..
"Advanced" setting is generally customization and resetting for battery and
grid. Each part has lower level parts.
Please contact your installer or factory and enter the installer password.
.
2) Grid Parameters
Here you can set the protection value of grid voltage and frequency. The
default value is the specified value under the current safety regulations,
and the user cannot change it .
The display content will be displayed according to the requirements of
local laws and regulations, which are constantly increasing. Please refer to
the contents displayed on the inverter screen.
Advance Password
26)
Pgrid Bias
27)
Exten BAT Func
28)
29)
Battery Charge EVC
3) Charger
Here the user can set the parameters of “Charger” on this page, the
inverter is compatible with both lithium battery and lead-acid battery. The
default battery type is lithium, users can change it to lead-acid in actual
usage. The relevant parameters needed to be set.
For the detailed parameters, please refer to the contents display on the
screen.
Battery Type
Lead Acid Lithium
Charger
Lead Acid
Charger
Charge Equalization
00.0V
Charger
Charger
Charge oat
00.0V
To Next Page
