For United Kingdom
• The installation that connects the equipment to the supply terminals
comply with the requirements of 7671.shall BS
• Electrical installation of system shall comply with requirements of PV
and 60364-7-712.BS IEC 7671
• No protection settings can be altered.
• Installer shall ensure that equipment is installed and operated to
at all times in compliance with the requirements of 22 maintain ESQCR
(1) (a) .
For Australia and New Zealand
• Electrical installation and maintenance shall be conducted by licensed
electrician and shall comply with Australia National Wiring Rules.
09
2.3 Explanation of Symbols
This section gives an explanation of all the symbols shown on the inverter and
on the type label.
● Symbols on the Inverter
● Symbols on the Type Label
Safety Safety
Communication indicator
Symbol Explanation
DC connection indicator
Grid connection indicator
Alarm indicator
Beware of hot surface.
The inverter can become hot during operation. Avoid contact
during operation.
Danger of high voltages.
Danger to life due to high voltages in the inverter!
Danger.
Risk of electric shock!
Observe enclosed documentation.
The inverter can not be disposed together with the household waste.
Disposal information can be found in the enclosed documentation.
Do not operate this inverter until it is isolated from mains
and on-site PV generation suppliers.
Danger to life due to high voltage.
There is residual voltage in the inverter which needs 5 minutes to
discharge.
• Wait 5 minutes before you open the upper lid or the DC lid.
08
TUV certificated
Symbol Explanation
CE mark.
The inverter complies with the requirements of the applicable
CE guildlines.
