15 • Mode Pages Display
________________________________________________________________________________________________
Press SELECT
Enabling, Disabling operation of RELAY B for T1 LEVEL 1.
Press ▲ or▼ keys to set if RELAY B will follow T1 LEVEL 1 settings.
Note: Relay operates upon T1 LEVEL 1 fault which is enabled if RELAY B is set to TRIPPING/ALARM in the
I/O SETTING PAGE.
Range: DISABLE, ENABLE
Press SELECT
Enabling, Disabling operation of RELAY C for T1 LEVEL 1.
Press ▲ or▼ keys to set if RELAY C will follow T1 LEVEL 1 settings.
Note: Relay operates upon T1 LEVEL 1 fault which is enabled if RELAY C is set to TRIPPING/ALARM in the
I/O SETTING PAGE.
Range: DISABLE, ENABLE
Press SELECT
Enabling, Disabling operation of RELAY D for T1 LEVEL 1.
Press ▲ or▼ keys to set if RELAY D will follow T1 LEVEL 1 settings.
Note: Relay operates upon T1 LEVEL 1 fault which is enabled if RELAY D is set to TRIPPING/ALARM in the
I/O SETTING PAGE.
Range: DISABLE, ENABLE
Press SELECT to see next Tx LEVEL 1, then all sensors with Tx LEVEL 2.
Press SELECT
Enabling, Disabling trip function upon closure of
EXTERNAL FAULT INPUT 1.
Press ▲ or▼ keys to set if EXTERNAL FAULT 1 is set
to TRIP the unit.
Range DISABLE, ENABLE
Press SELECT to see ALARM, AUTO RST, RELAY
A..RELAY D settings for EXTERNAL FAULT 1
Press SELECT
Enabling, Disabling trip function upon closure of
EXTERNAL FAULT INPUT 1.
Press ▲ or▼ keys to set if EXTERNAL FAULT 1 is set
to TRIP the unit.
Range DISABLE, ENABLE
Press SELECT to see ALARM, AUTO RST, RELAY
A..RELAY D settings for EXTERNAL FAULT 1
EXTERNAL FAULT 1
EXTERNAL FAULT 1 occurs when terminal
13 – CONFIG. INPUT 1 is set as EXTERNAL
FAULT 1 NO and the TPR detects a closed
circuit between terminal 13 terminal 15
(common) input terminals.
EXTERNAL FAULT 1 occurs when terminal
13 - CONFIG. INPUT 1 is set as EXTERNAL
FAULT 1 NC and the TPR-6 detects open
circuit between terminal 13 terminal 15
(common) input terminals.
EXTERNAL FAULT 2
EXTERNAL FAULT 2 occurs when terminal
14 – CONFIG. INPUT 2 is set as EXTERNAL
FAULT 2 NO and the TPR detects a closed
circuit between terminal 14 terminal 15
(common) input terminals.
EXTERNAL FAULT 2 occurs when terminal
14 - CONFIG. INPUT 2 is set as EXTERNAL
FAULT 2 NC and the TPR-6 detects open
circuit between terminal 14 terminal 15
(common) input terminals.
To Next Page
