Solid State Logic C100 HDS Software Update Manual

C100 HDS Software Update
Page 14
Saving Edited Cuts
The Save button in the Cut Edit window simply saves the Cut with its edits under the same name. Pressing the Save
button on a Cut which hasn’t been saved before will cause a keyboard to appear, in which the Cut can be named before
saving.
The Save As button allows the Cut to be saved with a new name, leaving the Cut on which it was based unchanged.
Note that all Cut edits are non-destructive. Any number of Cuts can be created using the same root audio file.
Press OK to close the Cut Edit window and return to the previous screen.
Note also that new Cuts are always saved in the same folder as the one on which it is based. The Cut’s location can be
altered via Samba Share. See ‘Uploading and Managing Audio Files for C-Play’ for details.
Note also that edits to Cuts are not project-specific – any changes made to a Cut will affect that Cut in every context in
which it is used.

Solid State Logic C100 HDS Specifications

Power

console power	100-240 V AC
power consumption	300-700 W

DSP and Audio Processing

maximum input channels	256
second input path channels	512
utility busses	24 mono
aux busses	24 mono
dedicated ASG buses	16
dedicated PGM buses	12
delay modules	64 modules, 5.4 seconds each

Weight and Dimensions

max height	100.6 cm
weight (40 fader)	190 kg
height adjustment	0 to +1 cm
width (40 fader, flat end trim)	143.1 cm
max depth	92.6 cm
