(2) Intended use
The product is intended for moving waste water, raw and clean water. Always
follow the limits given in Application limits (page 9). If there is a question
regarding the intended use of the equipment, ple ase contact a
Solidpump representative before proceeding.
WARNING:
Only Ex-approved pumps may be used in an explosive or flammable environment.
NOTICE:
Do not use the pump in highly corrosive liquids.
(3) The data plate The information of pump model
The information of pump model name
Motor power (kW)
Pump series
Discharging hose inner diam. (mm)
Motor power (kW)
Intelligent control system
Pump series
Discharging hose inner diam. (mm)
(4) Pump part names
NOTE:
This diagram shows the part layout of a typical TBZ/TBZE model. The
external appearance and the internal construction may vary slightly,
depending on your particular model.
5 6
