5
Contents
2-4 IDE Connector Installation ................................................. 22
2-5 Floppy Drive Connector Installation ................................. 23
2-6 Serial ATA Connectors (75FRN2-R / RL Only)................ 24
2-7 ATX Power Supply Installation .......................................... 25
2-8 Jumper Settings ..................................................................... 26
2-8.1 How to tackle the Jumpers: ....................................................... 27
2-8.2 Jp2: CPU Clock Select ................................................................ 27
2-8.3 JBAT1: nVIDIA Clear CMOS ................................................... 28
2-8.4 Jp5: Anti-burn Shield (ABSII) .................................................. 29
2-8.5 Jp1&Jp7: PS/2 KB/Mouse Power On ...................................... 30
2-8.6 Jp4: SATA RAID Controller Select(75FRN2-R/RL Only) ...30
2-9 Other Connectors Configuration........................................ 31
2-9.1 Onboard FAN Connectors ......................................................... 31
2-9.2 USB Ports and USB Pin-headers ..............................................32
2-9.3 Chassis Panel Connectors .......................................................... 33
2-9.4 PS/2 Mouse And PS/2 Keyboard ............................................... 33
2-9.5 CD-ROM Audio Connectors ...................................................... 34
2-9.6 Thermal Detectors .......................................................................34
2-9.7 Wake On LAN Connector:.........................................................35
2-9.8 Complex Pin-header (Front Panel Connectors) ..................... 36
2-9.9 Front Panel Audio Connector .................................................. 38
2-9.11 LAN Connector (75FRN2-L / RL Only).................................38
2-9.12 6 Channel Sound Output Connector(Optional) ................... 39
Chapter 3 Software Setup ....................................... 40
3-1 To Open up the Support CD ................................................ 41
3-2 To Install “nVIDIA nForce2 All-in-1 Driver” .................. 42
3-3 To Install AC’97 Audio Driver ............................................ 44
3-4 To Verify 6-channel Audio Configuration ......................... 45
3-5 To Install Hardware Monitor Utility.................................. 48
