Series 75FRN2: 75FRN2, 75FRN2-L, 75FRN2-R, 75FRN2-RL
Topics included in this chapter are:
1-1 Mainboard Layout
1-2 Mainboard Specifications**
1-3 Mainboard Specification Table
1-4 Chipset System Block Diagram
Introduction
Chapter 1 Specification
This series features an integration of the powerful AMD processors
Athlon/Athlon XP/Duron and the North Bridge nVIDIA nFORCE2 Ultra
400 (nFORCE2 SPP) plus South Bridge nFORCE2 MCP, with which
the whole system performance supports 400/333/266/200MHz system
bus.
nVIDIA nFORCE2 Ultra 400 (nFORCE2 SPP) plus nFORCE2 MCP
supports on-board AMD processors to implement the 400/333/266/200
MHz Front Side Bus, the AGP 8X/4X interface, the LPC Super I/O, the
Dual-channel DDR 400/333/266 MHz SDRAM, the 6-channel AC’97
Audio interface, the USB 2.0 interface and ATA 133/100/66 data trans-
fer rate. This chapter is to introduce to users every advanced function
of this high performance integration.
** If any difference is found between this manual and the Main-
board you are using, please look up the ERRATA/UPDATE Slip
enclosed inside for the correction or updated information, or
else contact the Mainboard Dealer or visit our Web Site for the
latest manual update.
