SOLTEK 75FRN2 Series - 4-6.8 Smartdoc Anti-Burn Shield

Series 75FRN2: 75FRN2, 75FRN2-L, 75FRN2-R, 75FRN2-RL
78
Shutdown By ABS II
(for AMD XP/Duron
Morgan)
This item will appear if AMD XP or Duron Morgan
CPU is running on board. ABS II (Anti-burn Shield
II) allows user to set up the safeguard temperature
for the CPU designed with a protective thermal di-
ode inside the CPU itself. Default Safeguard tem-
perature is 85˚C, at which the XP or Duron Morgan
CPU will shutdown. Usually, a jumper is also de-
signed on board for enabling/disabling ABS II
function.
Choices: 75˚C / 167˚F; 80˚C / 176˚F
85˚C / 185˚F(default); 90˚C / 194˚F
95˚C / 203˚F; 100˚C / 212˚F
This section helps you to get more information about your system in-
cluding CPU temperature, FAN speed and voltage. It is recommended
that you contact your mainboard supplier to get proper values about
the setting of the CPU temperature.
Run the “SmartDoc Anti-Burn Shield” as follows:
Choose “SmartDoc Anti-Burn Shield” from the Main Menu and a screen
with a list of options will appear:
4-6.8 SmartDoc Anti-Burn Shield
Shutdown By ABS II 85˚C / 185˚F
ABS II Temp. 72˚C / 161˚F
System Temp. 33˚C/ 93˚F
CPU External Temp. 42˚C/ 107˚F
Current CPUFAN1 Speed 5232 RPM
Current CPUFAN2 Speed 0 RPM
Current CPUFAN3 Speed 0 RPM
CPU Vcore 1.79 V
3.3V 3.26 V
+5V 5.02V
+12V 11.75V
-12V -11.74V
-5V -5.25V
VBAT(V) 1.53V
5VSB(V) 5.05V
Item Help
: Move Enter: Select +/-/PU/PD: Value F10: Save Esc: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Phoenix - AwardBIOS CMOS Setup Utility
SmartDoc Anti-Burn Shield
