Chapter 4 BIOS Setup
77
Reset Configuration
Data
Normally, you leave this Disabled(default). Select
Enabled to reset Extended System Configuration
Data (ESCD), when you exit Setup if you have in-
stalled a new add-on and the system reconfiguration
has caused such a serious conflict that the operat-
ing system cannot boot.
Resource Controlled
By
The Plug and Play Award BIOS can automatically
configure all the boot and Plug and Play-compat-
ible devices. If you select Auto(default), all the inter-
rupt request (IRQ) and DMA assignment fields will
not appear, as the BIOS automatically assigns them.
If you select Manual, the IRQ Resources item will
appear for your configuration (see below).
IRQ Resources Press Enter. Please refer to the list below:
IRQ-3 assigned to PCI Device
IRQ-4 assigned to PCI Device
IRQ-5 assigned to PCI Device
IRQ-7 assigned to PCI Device
IRQ-9 assigned to PCI Device
IRQ-10 assigned to PCI Device
IRQ-11 assigned to PCI Device
IRQ-12 assigned to PCI Device
IRQ-14 assigned to PCI Device
IRQ-15 assigned to PCI Device
Item Help
Phoenix - AwardBIOS CMOS Setup Utility
IRQ Resources
: Move Enter: Select +/-/PU/PD: Value F10: Save Esc: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
PCI/VGA Palette Snoop This option allows the BIOS to preview VGA status,
and to modify the information delivered from the
feature Connector of the VGA card to MPEG card.
This option can solve the display inversion to black
after you have used a MPEG card.
PCI Slot 1/2/3/4/5 IRQ
Assigned
Allows you to specify the IRQ for the PCI slots.
Choices: Auto; 3; 4; 5; 7; 9; 10; 11; 12; 14; 15
