Chapter 1 Specification
1-2.7 Multi-I/O Functions
• PCI EIDE Controller, supporting:
-- 2 ATA 133 / 100 / 66 IDE connectors supporting up to 4 IDE devices
• Dedicated IR Functions:
-- 1x5 IR connector dedicated to IR function with Infrared-IrDA (HPSIR)
and ASK (Amplitude Shift Keyed) IR
• Multi-mode parallel data transfer:
-- Standard mode, high speed mode ECP and enhanced mode EPP
• Floppy Drive Connector:
-- 1 FDD connector supporting 2 floppy drives with drive swap support
• Universal Serial Bus Transfer Mode:
-- USB V2.0 compliant, 480 MB/s USB Bus, supporting Windows 2000 / XP.
-- 4 built-in USB connectors and 1 more USB pin-header which require 1
additional USB cable to provide 4 more USB ports
• PS/2 Keyboard and PS/2 Mouse
• UARTs (Universal Asynchronous Receiver / Transmitter):
-- 2 serial ports (COM1 & COM2) on board
1-2.8 Expansion Slots
• 5 PCI Bus Master slots
• 1 AGP 8X/4X slot
• 3 DDR DIMM slots
1-2.6 Advanced System Power Management
Advanced Configuration and Power Interface incorporated in BIOS for
reducing power consumption :
• ACPI 1.0B compliant (Advanced Configuration and Power Interface),
including ACPI Suspend mode support (See Power management of
BIOS Setup)
• APM V1.2 compliant (Legacy Power Management)
• PS/2 Keyboard & Mouse Power On
• Real Time Clock (RTC) with date alarm, month alarm, and century
field
1-2.5 Accelerated Graphics Port (AGP) Interface
AGP Controller embedded on board, supporting:
• 1.5V(8X/4X) power mode only, 1 AGP Slot supported
• 8X 66MHz AD and SBA signaling; AGP pipelined split-transaction
long burst transfers up to 2GB/sec.
• AGP 8X/4X supported, AGP V3.0 compliant
