SOMFY EXAVIA - Product Description Continued; Dimensions and Weight of Gate Leaves; General View of the Installation

8
EN - EXAVIA installation and operating guide - SOMFY
EN
Dimensions and weight of gate leaves which can be motorised, based on the wind strength
Wind strength Effect Product EXAVIA
≥ 80 Km/h The wind is too strong to walk against Min./Max. width.
Max weight.
1.25/1.5 m
250 kg
< 80 Km/h
> 40 Km/h
The branches of the trees are moving
Min./Max. width.
Max weight.
1.25/2.5 m
250 kg
Min./Max. width.
Max weight.
1.25/1.5 m
250 kg
≤ 40 Km/h Sand is flying
Min./Max. width.
Max weight.
1.25/2.5 m
250 kg
Openworked gate
Semi-openworked gate Solid gate
 General view of the installation
A
B
C
D
E
F
G
H
Mark Designation Mark Designation
A
Area lighting* E Offset antenna*
B Video entry phone* F Flashing light
C Key lock* G Motors
D Photoelectric cells H Control unit
*optional accessories
