OPERATING MANUAL MIC-2 ver. 1.8
Remarks
- During the measurement cycle, the buzzer emits
a short single signal every five seconds, so it is
possible to record the chronological characteristics
of the resistance of the insulation under investiga-
tion.
- During measurements the AUTO-OFF is not ac-
tive.
- In the mode of voltage measurement the AUTO-
OFF countdown starts anew each time the voltage
is changed by more than 5V.
- Once a measurement has been concluded, the
last result is shown on the display along with the
symbol . The last result of the measurement
disappears if there is a voltage exceeding 20V at
the measurement terminals.
Additional information displayed by the
meter
and a
continuous
double
tone sonic
signal
The measured object is under a volt-
age exceeding 20V. The measure-
ment is blocked. During 5s a double
tone sonic signal is generated, and
then the meter displays the voltage of
the object. Disconnect the meter
from the object (both terminals)
immediately.
