OPERATING MANUAL MIC-2 ver. 1.8
There may be an attempt to dis-
charge the object before the meas-
urement, it will be signalled by means
of the displayed symbol . An at-
tempt to discharge is undertaken if
the voltage exceeds 20V, but is lower
than 100V.
The insulation resistance is too low,
the measurement is finished. The
symbol is displayed if after 10 sec-
onds from the moment the START
button is pushed, the measurement
voltage has not reached the adjusted
value, and also if during the meas-
urement the insulation is punched
through.
The measurement range has been
exceeded.
A warning regarding a high voltage at
the terminals of the meter.
The object is discharged.
2.2 Connection resistance
measurement
