SonicWALL NSA 240 - Hardware Overview; SonicWALL NSA 240 Front Panel

Page ii SonicWALL NSA 240 Front Panel
SonicWALL NSA 240 Front Panel
NSA 240
Provides power and test status
(refer to page 5)
PC Card Slot
(side of unit)
Provides an interface
for the WWAN PC
Card connection
USB Ports
For future application
Provides dedicated LAN/WAN port status as follows:
link/spd:
activity:
activity:
LAN/WAN Port Status
PC Card Status
Provides WWAN PC Card status as follows:
signal:
link/act:
Off=10M
Green=100M
Solid=link
Blinking=activity
Off=10M
Green=100M
Amber=1,000M
Solid=link
Blinking=activity
Off=10M
Green=100M
Amber=1,000M
Solid=link
Blinking=activity
Green=connected
Amber=negotiating
Solid=link
Blinking=activity
