Instruction for Use | HCA 56x and 8x8
Short telegram, OMS compliant : Long telegram for Walk-by reading :
 Identification number (information in header).
 Date and time.
 Consumption value.
 Set Day.
 Set Day value.
 Error code.
 Current radiator temperature.
 Current ambient temperature
 State of parameters.
 Identification number (information in header).
 Date and time.
 Consumption value.
 Set Day.
 Set Day value.
 18 monthly values for the cumulated consumption.
 Rating factor KC.
 Rating factor KQ.
 Current radiator temperature.
 Current ambient temperature.
 Maximum radiator temperature of the current
heating period.
 Maximum radiator temperature of the previous
heating period.
 Manipulation protection:
- Duration of the manipulations.
- Date of the last manipulation.
- Manipulation counter.
 Error code.
 Firmware version.
 Commissioning date
 State of parameters.
The following parameters are transmitted by Sontex 868 Radio wM-Bus:
The following information is transmitted by the Sontex 878 LoRaWAN®
Depending on the quality of the network reception, the heating cost allocator automatically
determines whether a short or long telegram is sent.
The content of these two telegrams can be configured either at the time of order or later with
the Superprog software.
AES 128 bits encryption is available for all radio versions.
Short or long telegram radio wM-Bus (868)
The choice of the telegram is done when ordering. It is not possible to select the
telegram type in the device itself.
Short Telegram (by default): Long Telegram (by default):
 Identification number (information in header).
 Date and time.
 Consumption value.
 Set Day.
 Set Day value.
 Error Flags
 Current radiator temperature.

Status of the parameters
 Internal Version
 Identification number (information in header).
 Date and time.
 Consumption value.
 Set Day.
 Set Day value.
 Error Flags
 Current radiator temperature.

Status of the parameters
 Internal Version
 Maximum radiator temperature of the previous
heating period.
 Maximum radiator temperature of the current
heating period.
 Manipulation protection:
- Duration of the manipulations.
- Date of the last manipulation.
- Manipulation counter.

Date de mise en service.

Kc Factor unit
 Kq Factor unit
