Instruction for Use | HCA 56x and 8x8
6.6 Readout
The current and monthly values recorded by the heat cost allocator 565 / 566 / 868 / 878 as
well as several other parameters can be readout over the optical interface or also over radio.
Optical Interface: Radio SONTEX 566 :
 Identification number (information in header).
 Date and time.
 Consumption value.
 Set Day.
 Set Day value.
 Maximum radiator temperature of previous heating
period.
 36 monthly values and 18 half monthly values for
cumulated consumption.
 18 monthly values for the maximum radiator tem-
perature.
 Rating factor KC.
 Rating factor KQ.
 Current radiator temperature.
 Current ambient temperature.
 Maximum radiator temperature of the current heat-
ing period.
 Manipulation protection:
- Duration of the manipulations.
- Date of the last manipulation.
- Manipulation counter.
 Error code.
 Firmware version.
 Commissioning date.
 State of parameters.
 36 half monthly values for the average ambient
temperature.
 Identification number (information in header).
 Date and time.
 Consumption value.
 Set Day.
 Set Day value.
 Maximum radiator temperature of previous heating
period.
 18 monthly values for cumulated consumption.
 Rating factor KC.
 Rating factor KQ.
 Current radiator temperature.
 Current ambient temperature.
 Maximum radiator temperature of the current hea-
ting period.
 Manipulation protection:
- Duration of the manipulations.
- Date of the last manipulation.
- Manipulation counter.
 Error code.
 Firmware version.
 Commissioning date.
 State of parameters.
 36 half monthly values for the average ambient
temperature.
 Cost per unit totalized.
 Parameter for Auto-reset totalizer.
 Statistics counters for Radio.
