10. COMhawk xt / Verona Gen 4 – Technical Data
VERONA Gen 4
Micro Controller
NXP iMX6DualLite 32bit- ARM Cortex-A9
800MHz
RAM
External: 512MB/1GB/2GB LPDDR3
External Flash extension
4/8/16/64 GB eMMC NAND Flash
EEPROM
1x EEPROM 32kBit
Real Time Clock
yes
CAN
2-4 CAN interfaces, all of them
- according to ISO 11898 standard, 2.0A
and 2.0B
CAN termination
Split termination in combination with CAN
transceiver
LIN
Optional either Master or Slave
WIFI
1x WIFI module 2,4 GHz ( IEEE 802.11 b/g/n)
with external FAKRA antenna
Bluetooth
1x integrated together with WiFi Module BLE
Ethernet
1x 100 Mbit Ethernet.
Digital Input
4x, up to 32V allowed
Digital Output
1x 1A output with PWM (Voltage Level V
BAT
)
with HSS
1x 5V output (optional 10 V)
Analog Input
4 x 0 – 24 V measurement
Power Supply
24V system: 16 – 32V / max. 1A (basic board
configuration)
12V system: 6 – 16V / max. 1A (basic board
configuration)
Range: 6 – 32V
Housing
Cinch housing with 30-pole automotive
connector
IP69K protection
Operating temperature
-40°C ... +85°C
Storage temperature
-40°C … +85°C
Extensions/Options
LAN
10/100 Mbit/s LAN for cable network
connection
GNSS
GNSS module: GPS/GLONASS, Galileo,
BeiDou with external FAKRA antenna
