Sontheim Verona COMhawk xt - Antenna Specifications; Table 4 Bands, Frequencies, Maximum Power and Maximum Antenna Gain for EC; Table 5 Bands, Frequencies, Maximum Power and Maximum Antenna Gain for FCC; ISED

Operations Manual
© Sontheim Industrie Elektronik GmbH 13.05.2022 page 14 of 30
Sontheim_Telemetry_Verona_Gen 4_operations manual.docx Version of the Document: 2.1
Table 4 Bands, frequencies, maximum power and maximum antenna gain for EC
Technologies
Max. power
[dBm]
Antenna gain
max.:
[dBi]
conducted
E GPRS 850 MHz
31dBm±2dB
E GPRS 1900 MHz
28dBm±2dB
LTE FDD 2 1900 MHz
23dBm±2dB
1.87
LTE FDD 4 1750 MHz
23dBm±2dB
3.12
LTE FDD 5 850 MHz
23dBm±2dB
0.91
LTE FDD 12 700 MHz
23dBm±2dB
0.95
LTE FDD 13 700 MHz
21dBm±2dB
2.23
LTE FDD 25 1900 MHz
23dBm±2dB
1.87
LTE FDD 26 850 MHz
23dBm±2dB
0.91
LTE TDD 41 2600 MHz
22dBm±2dB
2.90
LTE FDD 66 2150 MHz
23dBm±2dB
3.12
WLAN 2450 MHz
15.0
3.0
Table 5 Bands, frequencies, maximum power and maximum antenna gain for FCC / ISED
11.2. Antenna Specifications
For LTE band use a 0 dBi gain antenna, to be compliant with Table 5 Bands, frequencies, maximum
power and maximum antenna gain for FCC / ISED.
For WiFi, use a maximum 3 dBi antenna for 2.4 GHz frequency band
The maximum antenna gain is listed in the chapter 11.1 GSM/UMTS/LTE RF Specifications.
Use only the following antenna, this antenna was part of the certification:
Antenna: Hirschmann (TE): CGNW 702659 LP S/FAKRAf/3.0
Or alternative:
Antenna Molex 206866
