Sontheim Verona COMhawk xt - RF Specifications; GSM;UMTS;LTE RF Parameters

Operations Manual
© Sontheim Industrie Elektronik GmbH 13.05.2022 page 13 of 30
Sontheim_Telemetry_Verona_Gen 4_operations manual.docx Version of the Document: 2.1
Cellular
Cellular module with LTE CAT4/UMTS/GSM
support, external FAKRA antennas
Security
function integrated in iMX6
Temperature sensor
Temp. range -55 up to +125°C, 3% accuracy
Acceleration sensor
3-axis
Gyroscope-sensor
3-axis
LED
2x 3-color LEDs
Software
Operating System
Linux Kernel: 4.19 (4.19.219)
Boot Loader: U-Boot 2015.01
Certifications
ECE R10 type approval number
E1*10R06/01*9371*00
Machinery directive
Yes, compliant with 2006/42/EC (machinery
directive)
EMC
Yes, compliant with 2014/30/EC (EMC directive)
RF Compliance
Yes, compliant with 2014/53/EC (radio
equipment directive)
Low voltage
Yes compliant with 2014/35/EC (low voltage
directive
RoHS
Yes compliant with 2011/65/EC (RoHS)
HMN / HVIN
Verona GEN4
Table 3: System and Functional Requirements (Populated Option is Bold)
11. RF Specification
11.1. GSM/UMTS/LTE RF Specifications
Technologies
Max. power
[dBm]
Antenna gain
max.:
[dBi]
conducted
E GPRS 900 MHz
33dBm±2dB
0.03
E GPRS 1800 MHz
30dBm±2dB
3.12
LTE FDD 1 1950 MHz
23dBm±2dB
2.17
LTE FDD 3 1800 MHz
23dBm±2dB
3.12
LTE FDD 7 2600 MHz
23dBm±2dB
3.2
LTE FDD 8 900 MHz
23dBm±2dB
0.03
LTE FDD 28 700 MHz
23dBm±2dB
1.57
LTE TDD 40 2300 MHz
23dBm±2dB
3.52
WLAN 2450 MHz
15.0
3.0
