– 52 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
* 1-666-289-11 AC SW BOARD
************
< CAPACITOR >
! C991 1-113-925-11 CERAMIC 0.01uF 20% 250V
< SWITCH >
! S991 1-572-267-51 SWITCH, PUSH (AC POWER) (1 KEY) (POWER)
************************************************************
* A-4699-761-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C102 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C103 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C104 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C107 1-136-850-11 FILM 0.1uF 5% 63V
C108 1-163-035-00 CERAMIC CHIP 0.047uF 50V
C109 1-163-145-00 CERAMIC CHIP 0.0015uF 5% 50V
C110 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C111 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C112 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C113 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C115 1-124-673-11 ELECT 100uF 20% 10V
C116 1-124-673-11 ELECT 100uF 20% 10V
C117 1-126-209-11 ELECT 100uF 20% 4V
C118 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C119 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C120 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C123 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C124 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C131 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C132 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C151 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C152 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C153 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C154 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C155 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C156 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C157 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C158 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C159 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C160 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C161 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C162 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C171 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C172 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C173 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C191 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C192 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C193 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C194 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C261 1-126-177-11 ELECT 100uF 20% 10V
C325 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C360 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C370 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C371 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C372 1-126-177-11 ELECT 100uF 20% 10V
< CONNECTOR >
CN101 1-691-894-21 SOCKET, CONNECTOR 16P
* CN102 1-568-864-11 SOCKET, CONNECTOR 21P
* CN103 1-568-941-11 PIN, CONNECTOR 3P
CN104 1-564-517-11 PLUG, CONNECTOR 2P
* CN105 1-564-518-11 PLUG, CONNECTOR 3P
* CN106 1-568-854-11 SOCKET, CONNECTOR 11P
* CN107 1-568-850-11 SOCKET, CONNECTOR 7P
* CN108 1-568-847-11 SOCKET, CONNECTOR 4P
CN113 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D101 8-719-016-74 DIODE 1SS352
D361 8-719-938-07 LED GL480
< IC >
IC101 8-752-369-78 IC CXD2545Q
IC102 8-759-071-79 IC BA6297AFP
IC103 8-752-072-45 IC CXA1821M-T6
SECTION 8
ELECTRICAL PARTS LIST
AC SW
The components identified by mark
! or dotted line with mark ! are
critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
When indicating parts by reference
number, please include the board.
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used on
the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Abbreviation
CND : Canadian
SP : Singapore
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
BD
