– 54 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
* A-4699-752-A DISP BOARD, COMPLETE
*********************
* 4-955-901-01 CUSHION (FL)
< CAPACITOR >
C751 1-163-101-00 CERAMIC CHIP 22PF 5% 50V
C752 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C753 1-124-584-00 ELECT 100uF 20% 10V
C754 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C755 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C756 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C757 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C801 1-163-038-00 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
* CN806 1-568-854-11 SOCKET, CONNECTOR 11P
< FLUORECENT INDICATOR >
FLD801 1-519-757-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC801 8-759-399-58 IC LC75725E
IC804 8-759-459-83 IC NJL55H400
< TRANSISTOR >
Q701 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R751 1-216-025-00 METAL GLAZE 100 5% 1/10W
R752 1-216-073-00 METAL CHIP 10K 5% 1/10W
R753 1-216-033-00 METAL CHIP 220 5% 1/10W
R754 1-216-033-00 METAL CHIP 220 5% 1/10W
R755 1-216-033-00 METAL CHIP 220 5% 1/10W
R756 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R817 1-216-045-00 METAL CHIP 680 5% 1/10W
< SWITCH >
S819 1-554-303-21 SWITCH, TACTILE (TIME)
S820 1-554-303-21 SWITCH, TACTILE (PLAY MODE)
************************************************************
* A-4699-747-A FUNC BOARD, COMPLETE
*********************
< CONNECTOR >
* CN817 1-568-850-11 SOCKET, CONNECTOR 7P
< LED >
D801 8-719-303-02 LED SEL2510C-D (()
D802 8-719-301-52 LED SEL2810A-C (P)
< TRANSISTOR >
Q801 8-729-900-80 TRANSISTOR DTC114ES
Q802 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R801 1-216-045-00 METAL CHIP 680 5% 1/10W
R802 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R803 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R804 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R805 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R806 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R811 1-216-045-00 METAL CHIP 680 5% 1/10W
R812 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R813 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R814 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R815 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R816 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R821 1-216-027-00 METAL CHIP 120 5% 1/10W
R822 1-216-035-00 METAL CHIP 270 5% 1/10W
R831 1-216-077-00 METAL CHIP 15K 5% 1/10W
R832 1-216-077-00 METAL CHIP 15K 5% 1/10W
< ROTARY ENCODER >
RV801 1-475-006-11 ENCODER, ROTARY
(≠ AMS ± PUSH ENTER)
< SWITCH >
S801 1-554-303-21 SWITCH, TACTILE (AUTO SPACE)
S802 1-554-303-21 SWITCH, TACTILE (CHECK)
S803 1-554-303-21 SWITCH, TACTILE (CLEAR)
S804 1-554-303-21 SWITCH, TACTILE (FADER)
S805 1-554-303-21 SWITCH, TACTILE (0)
S806 1-554-303-21 SWITCH, TACTILE ())
S811 1-554-303-21 SWITCH, TACTILE (EDIT/TIME FADE)
S812 1-554-303-21 SWITCH, TACTILE (REPEAT)
S813 1-554-303-21 SWITCH, TACTILE (PEAK SEARCH)
S814 1-554-303-21 SWITCH, TACTILE (§ OPEN/CLOSE)
S815 1-554-303-21 SWITCH, TACTILE (()
S816 1-554-303-21 SWITCH, TACTILE (P)
S817 1-554-303-21 SWITCH, TACTILE (p)
************************************************************
* 1-666-288-11 HP BOARD (EXCEPT UK)
*********
* 4-962-201-01 PLATE (HP), GROUND
< CAPACITOR >
C371 1-124-443-00 ELECT 100uF 20% 10V
C372 1-163-033-00 CERAMIC CHIP 0.022uF 50V
C471 1-162-294-31 CERAMIC 0.001uF 10% 50V
C472 1-162-294-31 CERAMIC 0.001uF 10% 50V
C473 1-163-038-00 CERAMIC CHIP 0.1uF 25V
DISP FUNC HP
