– 55 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< CONNECTOR >
* CN371 1-568-847-11 SOCKET, CONNECTOR 4P
CN471 1-564-523-11 PLUG, CONNECTOR 8P
* CN472 1-564-518-11 PLUG, CONNECTOR 3P
< IC >
IC371 8-759-962-08 IC BA6208
< JACK >
J471 1-750-162-61 JACK (LARGE TYPE) (PHONES) (BLACK)
(US, CND, AEP, SP)
J471 1-779-219-11 JACK (LARGE TYPE) (PHONES) (GOLD)
(AEP, SP)
< COIL >
L471 1-424-122-11 FILTER, NOISE
L472 1-424-122-11 FILTER, NOISE
L473 1-424-122-11 FILTER, NOISE
< RESISTOR >
R371 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R372 1-216-049-11 METAL GLAZE 1K 5% 1/10W
< VARIABLE RESISTOR >
RV471 1-223-747-11 RES, VAR, CARBON 10K/10K
(LINE OUT PHONE LEVEL)
************************************************************
* 1-666-163-11 LD IN SW BOARD
**************
< SWITCH >
S152 1-762-424-11 SWITCH, MICRO (LOAD IN)
************************************************************
* A-4699-759-A LOADING MOTOR BOARD, COMPLETE
*******************************
< CAPACITOR >
C181 1-126-023-11 ELECT 100uF 20% 25V
C182 1-126-023-11 ELECT 100uF 20% 25V
C183 1-164-699-11 CERAMIC CHIP 0.0033uF 5% 50V
C184 1-126-059-11 ELECT 10uF 20% 50V
C185 1-163-038-00 CERAMIC CHIP 0.1uF 25V
< IC >
IC181 8-759-202-01 IC TA7256P
IC182 8-759-100-96 IC uPC4558G2
< RESISTOR >
R001 1-216-073-00 METAL CHIP 10K 5% 1/10W
R002 1-216-073-00 METAL CHIP 10K 5% 1/10W
R003 1-216-073-00 METAL CHIP 10K 5% 1/10W
R004 1-216-073-00 METAL CHIP 10K 5% 1/10W
R005 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R006 1-216-047-00 METAL GLAZE 820 5% 1/10W
R007 1-216-025-00 METAL GLAZE 100 5% 1/10W
R008 1-216-045-00 METAL CHIP 680 5% 1/10W
! R009 1-249-474-11 CARBON 1 5% 1/2W F
R010 1-216-001-00 METAL CHIP 10 5% 1/10W
************************************************************
* A-4699-745-A MAIN BOARD, COMPLETE (US, CND)
* A-4699-749-A MAIN BOARD, COMPLETE (AEP)
* A-4699-755-A MAIN BOARD, COMPLETE (UK)
* A-4699-757-A MAIN BOARD, COMPLETE (SP)
*********************
< CAPACITOR >
C259 1-163-033-00 CERAMIC CHIP 0.022uF 50V
(AEP, UK)
C260 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
(AEP, UK)
C271 1-124-994-11 ELECT 100uF 20% 10V
C272 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C274 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C301 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C302 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C306 1-162-208-31 CERAMIC 24PF 5% 50V
C321 1-128-202-11 ELECT 220uF 20% 63V
C322 1-136-850-11 FILM 0.1uF 5% 63V
C323 1-102-942-00 CERAMIC 5.0PF ±0.5PF50V
C324 1-102-942-00 CERAMIC 5.0PF ±0.5PF50V
C353 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C358 1-126-059-11 ELECT 10uF 20% 50V
(EXCEPT UK)
C359 1-128-201-11 ELECT 100uF 20% 63V
C370 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C415 1-136-818-11 FILM 0.0047uF 5% 100V
C416 1-136-818-11 FILM 0.0047uF 5% 100V
C420 1-136-850-11 FILM 0.1uF 5% 63V
C502 1-126-023-11 ELECT 100uF 20% 25V
C503 1-136-850-11 FILM 0.1uF 5% 63V
C505 1-136-850-11 FILM 0.1uF 5% 63V
C506 1-136-850-11 FILM 0.1uF 5% 63V
C510 1-128-197-11 ELECT 10uF 20% 50V
C512 1-136-802-11 FILM 0.015uF 5% 100V
C513 1-136-850-11 FILM 0.1uF 5% 63V
C516 1-136-850-11 FILM 0.1uF 5% 63V
C517 1-136-850-11 FILM 0.1uF 5% 63V
C518 1-136-850-11 FILM 0.1uF 5% 63V
C519 1-128-198-11 ELECT 22uF 20% 63V
C520 1-128-198-11 ELECT 22uF 20% 63V
C521 1-130-973-00 FILM 0.022uF 5% 100V
C522 1-130-955-00 FILM 0.01uF 5% 100V
C523 1-130-955-00 FILM 0.01uF 5% 100V
C524 1-136-233-11 FILM 0.0047uF 3% 100V
C525 1-136-233-11 FILM 0.0047uF 3% 100V
C526 1-136-814-11 FILM 0.001uF 5% 100V
MAIN
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
LOADING MOTORLD IN SWHP
To Next Page
