– 56 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C527 1-136-814-11 FILM 0.001uF 5% 100V
C530 1-136-816-11 FILM 0.0022uF 5% 100V
C531 1-136-816-11 FILM 0.0022uF 5% 100V
C532 1-128-201-11 ELECT 100uF 20% 50V
C533 1-136-580-11 FILM 0.47uF 10% 200V
C536 1-128-198-11 ELECT 22uF 20% 63V
C537 1-128-201-11 ELECT 100uF 20% 50V
C601 1-136-850-11 FILM 0.1uF 5% 63V
C602 1-126-023-11 ELECT 100uF 20% 25V
C603 1-136-850-11 FILM 0.1uF 5% 63V
C605 1-136-850-11 FILM 0.1uF 5% 63V
C610 1-128-197-11 ELECT 10uF 20% 50V
C612 1-136-802-11 FILM 0.015uF 5% 100V
C613 1-136-850-11 FILM 0.1uF 5% 63V
C616 1-136-850-11 FILM 0.1uF 5% 63V
C617 1-136-850-11 FILM 0.1uF 5% 63V
C618 1-136-850-11 FILM 0.1uF 5% 63V
C619 1-128-198-11 ELECT 22uF 20% 63V
C620 1-128-198-11 ELECT 22uF 20% 63V
C621 1-130-973-00 FILM 0.022uF 5% 100V
C622 1-130-955-00 FILM 0.01uF 5% 100V
C623 1-130-955-00 FILM 0.01uF 5% 100V
C624 1-136-233-11 FILM 0.0047uF 3% 100V
C625 1-136-233-11 FILM 0.0047uF 3% 100V
C626 1-136-814-11 FILM 0.001uF 5% 100V
C627 1-136-814-11 FILM 0.001uF 5% 100V
C630 1-136-816-11 FILM 0.0022uF 5% 100V
C631 1-136-816-11 FILM 0.0022uF 5% 100V
C632 1-128-201-11 ELECT 100uF 20% 50V
C633 1-136-580-11 FILM 0.47uF 10% 200V
C636 1-128-198-11 ELECT 22uF 20% 63V
C637 1-128-201-11 ELECT 100uF 20% 50V
< CONNECTOR >
CN201 1-564-506-11 PLUG, CONNECTOR 3P
* CN301 1-568-835-11 SOCKET, CONNECTOR 16P
CN303 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
CN304 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CN501 1-564-511-11 PLUG, CONNECTOR 8P (EXCEPT UK)
* CN502 1-564-506-11 PLUG, CONNECTOR 3P (EXCEPT UK)
< DIODE >
D1 8-719-016-74 DIODE 1SS352 (AEP, UK)
D2 8-719-016-74 DIODE 1SS352 (AEP, UK)
D3 8-719-016-74 DIODE 1SS352
D4 8-719-016-74 DIODE 1SS352
D302 8-719-010-26 DIODE UZ-3.9BSB-TP
D303 8-719-016-74 DIODE 1SS352
D311 8-719-016-74 DIODE 1SS352
D352 8-719-016-74 DIODE 1SS352 (EXCEPT UK)
< IC >
IC208 8-749-921-12 IC GP1F32T (DIGITAL OUT OPTICAL)
IC251 8-759-242-70 IC TC7WU04F
IC302 8-759-370-62 IC CXD8505BQ
IC501 8-759-371-51 IC CXA8042AS
IC502 8-759-712-02 IC NJM2114D
IC503 8-759-602-83 IC M5238P
IC551 8-759-981-86 IC RC4556MA (EXCEPT UK)
IC601 8-759-371-51 IC CXA8042AS
IC602 8-759-712-02 IC NJM2114D
IC603 8-759-602-83 IC M5238P
< JACK >
J301 1-569-442-21 JACK, PIN 2P (LINE OUT) (UK)
J301 1-569-443-21 JACK, PIN 4P (LINE OUT) (EXCEPT UK)
J351 1-770-905-21 JACK, PIN 1P (DIGITAL OUT COAXIAL)
(AEP, UK)
< COIL >
L1 1-410-375-11 INDUCTOR CHIP 3.3uH
L2 1-410-375-11 INDUCTOR CHIP 3.3uH
L302 1-410-503-11 INDUCTOR 3.3uH
L303 1-410-322-11 INDUCTOR 3.3uH
L315 1-410-970-11 INDUCTOR CHIP 6.8uH
L316 1-410-970-11 INDUCTOR CHIP 6.8uH
L401 1-410-970-11 INDUCTOR 6.8uH
< TRANSISTOR >
Q301 8-729-900-65 TRANSISTOR DTA144ES
Q351 8-729-422-57 TRANSISTOR UN4111 (EXCEPT UK)
Q503 8-729-231-55 TRANSISTOR 2SC2878-AB (EXCEPT UK)
Q504 8-729-900-65 TRANSISTOR DTA144ES (EXCEPT UK)
Q551 8-729-141-30 TRANSISTOR 2SC3623A-LK (EXCEPT UK)
Q603 8-729-231-55 TRANSISTOR 2SC2878-AB (EXCEPT UK)
Q604 8-729-900-65 TRANSISTOR DTA144ES (EXCEPT UK)
Q651 8-729-141-30 TRANSISTOR 2SC3623A-LK (EXCEPT UK)
< RESISTOR >
R1 1-216-001-00 METAL CHIP 10 5% 1/10W
R2 1-216-001-00 METAL CHIP 10 5% 1/10W
(AEP, UK)
R255 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R256 1-216-017-00 METAL GLAZE 47 5% 1/10W
R258 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R259 1-216-049-11 METAL GLAZE 1K 5% 1/10W
(AEP, UK)
R260 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R262 1-216-017-00 METAL GLAZE 47 5% 1/10W
(AEP, UK)
R263 1-216-001-00 METAL CHIP 10 5% 1/10W
(AEP, UK)
R301 1-216-089-00 METAL GLAZE 47K 5% 1/10W
R302 1-216-073-00 METAL CHIP 10K 5% 1/10W
R306 1-216-049-11 METAL GLAZE 1K 5% 1/10W
R311 1-216-037-00 METAL CHIP 330 5% 1/10W
R312 1-216-037-00 METAL CHIP 330 5% 1/10W
R313 1-216-037-00 METAL CHIP 330 5% 1/10W
MAIN
