Rear Panel
1342
1AUDIO OUT connector
Outputs analog audio signals.
2SCSI bus setting jumper block
Specifies various SCSI bus settings. See page 12 for details.
3interface CONNECT OR (SCSI b us)
Connect to a SCSI host adapter using a connecting cable.
4DC INPUT (po wer-in) connector
Connect to the power supply of the host computer.
Location and Function of Parts and Controls
Pin 1
