Sony CDX-3167 - Page 37

– 53 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< IC >
IC1 8-752-372-94 IC CXD2507AQ
IC2 8-752-069-56 IC CXA1782BQ
IC3 8-759-354-16 IC BA6796FP-T1
< JUMPER RESISTOR >
JR1 1-216-296-00 CONDUCTOR, CHIP (3216)
JR2 1-216-296-00 CONDUCTOR, CHIP (3216)
JR3 1-216-296-00 CONDUCTOR, CHIP (3216)
JR4 1-216-296-00 CONDUCTOR, CHIP (3216)
JR5 1-216-296-00 CONDUCTOR, CHIP (3216)
JR6 1-216-296-00 CONDUCTOR, CHIP (3216)
JR7 1-216-296-00 CONDUCTOR, CHIP (3216)
JR8 1-216-296-00 CONDUCTOR, CHIP (3216)
JR9 1-216-296-00 CONDUCTOR, CHIP (3216)
JR10 1-216-296-00 CONDUCTOR, CHIP (3216)
JR11 1-216-296-00 CONDUCTOR, CHIP (3216)
JR12 1-216-296-00 CONDUCTOR, CHIP (3216)
JR13 1-216-296-00 CONDUCTOR, CHIP (3216)
JR14 1-216-296-00 CONDUCTOR, CHIP (3216)
JR15 1-216-296-00 CONDUCTOR, CHIP (3216)
JR16 1-216-296-00 CONDUCTOR, CHIP (3216)
JR17 1-216-296-00 CONDUCTOR, CHIP (3216)
JR18 1-216-296-00 CONDUCTOR, CHIP (3216)
JR19 1-216-296-00 CONDUCTOR, CHIP (3216)
JR20 1-216-296-00 CONDUCTOR, CHIP (3216)
JR21 1-216-296-00 CONDUCTOR, CHIP (3216)
JR22 1-216-296-00 CONDUCTOR, CHIP (3216)
JR23 1-216-296-00 CONDUCTOR, CHIP (3216)
JR24 1-216-296-00 CONDUCTOR, CHIP (3216)
JR25 1-216-296-00 CONDUCTOR, CHIP (3216)
JR26 1-216-296-00 CONDUCTOR, CHIP (3216)
JR27 1-216-296-00 CONDUCTOR, CHIP (3216)
JR28 1-216-296-00 CONDUCTOR, CHIP (3216)
JR29 1-216-296-00 CONDUCTOR, CHIP (3216)
JR30 1-216-296-00 CONDUCTOR, CHIP (3216)
JR31 1-216-296-00 CONDUCTOR, CHIP (3216)
JR32 1-216-296-00 CONDUCTOR, CHIP (3216)
JR33 1-216-296-00 CONDUCTOR, CHIP (3216)
JR34 1-216-296-00 CONDUCTOR, CHIP (3216)
JR35 1-216-296-00 CONDUCTOR, CHIP (3216)
JR36 1-216-296-00 CONDUCTOR, CHIP (3216)
JR37 1-216-296-00 CONDUCTOR, CHIP (3216)
JR38 1-216-296-00 CONDUCTOR, CHIP (3216)
JR39 1-216-296-00 CONDUCTOR, CHIP (3216)
JR40 1-216-296-00 CONDUCTOR, CHIP (3216)
JR41 1-216-296-00 CONDUCTOR, CHIP (3216)
JR43 1-216-296-00 CONDUCTOR, CHIP (3216)
JR44 1-216-296-00 CONDUCTOR, CHIP (3216)
JR45 1-216-296-00 CONDUCTOR, CHIP (3216)
JR46 1-216-296-00 CONDUCTOR, CHIP (3216)
< COIL >
L1 1-412-058-11 INDUCTOR CHIP 10uH
L2 1-412-058-11 INDUCTOR CHIP 10uH
L3 1-412-058-11 INDUCTOR CHIP 10uH
< TRANSISTOR >
Q1 8-729-904-60 TRANSISTOR DTB113ZK
Q2 8-729-904-86 TRANSISTOR 2SB1197K-Q
< RESISTOR >
R1 1-216-073-00 METAL CHIP 10K 5% 1/10W
R2 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R3 1-216-121-00 METAL GLAZE 1M 5% 1/10W
R4 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R5 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R6 1-216-073-00 METAL CHIP 10K 5% 1/10W
R7 1-216-009-00 METAL CHIP 22 5% 1/10W
R8 1-216-119-00 METAL CHIP 820K 5% 1/10W
R9 1-216-119-00 METAL CHIP 820K 5% 1/10W
R10 1-216-073-00 METAL CHIP 10K 5% 1/10W
R11 1-216-073-00 METAL CHIP 10K 5% 1/10W
R14 1-216-085-00 METAL CHIP 33K 5% 1/10W
R15 1-216-085-00 METAL CHIP 33K 5% 1/10W
R16 1-216-077-00 METAL CHIP 15K 5% 1/10W
R17 1-216-081-00 METAL CHIP 22K 5% 1/10W
R19 1-216-079-00 METAL CHIP 18K 5% 1/10W
R20 1-216-105-00 METAL GLAZE 220K 5% 1/10W
R21 1-216-105-00 METAL GLAZE 220K 5% 1/10W
R22 1-216-085-00 METAL CHIP 33K 5% 1/10W
R23 1-216-121-00 METAL GLAZE 1M 5% 1/10W
R24 1-216-073-00 METAL CHIP 10K 5% 1/10W
R27 1-216-295-00 CONDUCTOR, CHIP (2012)
R28 1-216-101-00 METAL CHIP 150K 5% 1/10W
R29 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R30 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R31 1-216-081-00 METAL CHIP 22K 5% 1/10W
R32 1-216-109-00 METAL CHIP 330K 5% 1/10W
R33 1-216-105-00 METAL GLAZE 220K 5% 1/10W
R34 1-216-009-00 METAL CHIP 22 5% 1/10W
R35 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R36 1-216-097-00 METAL GLAZE 100K 5% 1/10W
R37 1-216-117-00 METAL CHIP 680K 5% 1/10W
R38 1-216-109-00 METAL CHIP 330K 5% 1/10W
R39 1-216-101-00 METAL CHIP 150K 5% 1/10W
R40 1-216-114-00 METAL GLAZE 510K 5% 1/10W
SERVO
