39
CDX-CA600/CA600X
R922 1-247-816-11 CARBON 240 5% 1/4W
R923 1-216-845-11 METAL CHIP 100K 5% 1/16W
R924 1-249-421-11 CARBON 2.2K 5% 1/4W
R925 1-216-821-11 METAL CHIP 1K 5% 1/16W
R926 1-249-413-11 CARBON 470 5% 1/4W
R927 1-249-417-11 CARBON 1K 5% 1/4W
R930 1-216-845-11 METAL CHIP 100K 5% 1/16W
R931 1-249-421-11 CARBON 2.2K 5% 1/4W
R932 1-216-805-11 METAL CHIP 47 5% 1/16W
R933 1-216-841-11 METAL CHIP 47K 5% 1/16W
R934 1-216-845-11 METAL CHIP 100K 5% 1/16W
R935 1-249-421-11 CARBON 2.2K 5% 1/4W
< SWITCH >
S801 1-762-638-21 SWITCH, TACTILE (RESET)
< THERMISTOR (POSITIVE) >
TH900 1-801-792-21 THERMISTOR, POSITIVE
TH901 1-810-940-11 THERMISTOR, POSITIVE
< TUNER >
TU601 A-3220-812-A TUNER UNIT (TUX-020)
< VIBRATOR >
X601 1-760-556-31 VIBRATOR, CRYSTAL (4.332MHz)
X801 1-781-822-21 VIBRATOR, CERAMIC (18.432MHz)
X802 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
*************************************************************
A-3283-233-A SERVO BOARD, COMPLETE
**********************
1-683-284-11 FLEXIBLE BOARD
< CAPACITOR >
C1 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4 1-104-609-11 ELECT CHIP 100uF 20% 4V
C5 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C6 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C8 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C9 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
C10 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
C11 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C13 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C14 1-125-837-00 CERAMIC CHIP 1uF 10% 6.3V
C15 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C16 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C17 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C18 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C19 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C20 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C21 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C22 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C23 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C24 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C25 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C26 1-126-391-11 ELECT CHIP 47uF 20% 6.3V
C27 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C29 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C30 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C34 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C35 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C36 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C37 1-126-393-11 ELECT CHIP 33uF 20% 10V
C38 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C40 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C41 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C43 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C44 1-125-837-00 CERAMIC CHIP 1uF 10% 6.3V
C45 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN1 1-815-352-11 CONNECTOR, BOARD TO BOARD 30P
CN3 1-816-275-11 CONNECTOR, FFC/FPC 6P
< JUMPER RESISTOR >
FB1 1-216-864-11 METAL CHIP 0 5% 1/16W
FB2 1-216-864-11 METAL CHIP 0 5% 1/16W
FB3 1-216-864-11 METAL CHIP 0 5% 1/16W
FB4 1-216-864-11 METAL CHIP 0 5% 1/16W
FB6 1-216-864-11 METAL CHIP 0 5% 1/16W
FB7 1-216-864-11 METAL CHIP 0 5% 1/16W
< IC >
IC1 8-759-699-98 IC uPD63711GC-8EU
IC2 8-759-658-87 IC BA5810FP-E2
< TRANSISTOR >
Q1 8-729-904-87 TRANSISTOR 2SB1197K-R
< RESISTOR >
R3 1-216-797-11 METAL CHIP 10 5% 1/16W
R5 1-218-344-11 RES-CHIP 7.5K 5% 1/16W
R6 1-216-837-11 METAL CHIP 22K 5% 1/16W
R7 1-216-839-11 METAL CHIP 33K 5% 1/16W
R8 1-216-833-11 METAL CHIP 10K 5% 1/16W
R9 1-216-840-11 METAL CHIP 39K 5% 1/16W
R10 1-216-835-11 METAL CHIP 15K 5% 1/16W
R12 1-216-837-11 METAL CHIP 22K 5% 1/16W
R14 1-216-841-11 METAL CHIP 47K 5% 1/16W
R15 1-216-841-11 METAL CHIP 47K 5% 1/16W
R17 1-216-809-11 METAL CHIP 100 5% 1/16W
R18 1-216-809-11 METAL CHIP 100 5% 1/16W
R19 1-216-809-11 METAL CHIP 100 5% 1/16W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
