CDX-F5000/FW500
4-2. FRONT PANEL SECTION
Ref. No. Part No. Description RemarkRef. No. Part No. Description Remark
51 X-3384-285-1 BUTTON KIT (SVX) ASSY
52 X-3384-637-1 KNOB VOL (SVX) ASSY
53 X-3384-283-1 PANEL ASSY (SVX), FRONT (F5000)
53 X-3384-326-1 PANEL ASSY (SVX), FRONT (FW500)
54 1-780-097-11 CONDUCTIVE BOARD, CONNECTION
55 X-3384-501-1 PLATE SUB ASSY (N), LIGHT GUIDE
56 X-3384-284-1 PANEL ASSY (SVX), FRONT BACK
57 X-3378-390-3 CASE (PANEL) ASSY (for FRONT PANEL)
58 A-3220-955-A FP-CDX-F5000//C (U) (F5000)
58 A-3220-967-A FP-CDX-FW500//C (U) (FW500)
LCD901 1-805-456-11 DISPLAY PANEL, LIQUID CRYSTAL (F5000)
LCD901 1-805-456-21 DISPLAY PANEL, LIQUID CRYSTAL (FW500)
#3 7-685-106-19 SCREW +P 2X10 TYPE2 NON-SLIT
51
52
53
not supplied
not supplied
(DISPLAY board)
LCD901
#3
#3
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
54
55
56
57
58
