37
CDX-F5000/FW500
SECTION 5
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
•Abbreviation
CND : Canadian model
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
DISPLAY BOARD
**************
1-780-097-11 CONDUCTIVE BOARD, CONNECTION
< CAPACITOR >
C951 1-135-834-11 CERAMIC CHIP 2.2uF 6.3V
C952 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C953 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C954 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C955 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C956 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C957 1-135-834-11 CERAMIC CHIP 2.2EuF 6.3V
C958 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN901 1-817-158-11 PLUG, CONNECTOR 14P
< DIODE >
D902 8-719-978-33 DIODE DTZ-TT11-6.8B
D903 8-719-978-33 DIODE DTZ-TT11-6.8B
D904 8-719-978-33 DIODE DTZ-TT11-6.8B
D905 8-719-988-61 DIODE 1SS355TE-17
D906 8-719-978-33 DIODE DTZ-TT11-6.8B
D951 8-719-069-54 DIODE UDZS-TE17-5.1B
< IC >
IC901 8-759-826-21 IC LC75874W
IC905 6-705-374-01 IC MM3033DULE
IC951 6-600-321-01 IC KSM-401Y (IR)
< LIQUID CRYSTAL DISPLAY >
LCD901 1-805-456-11 DISPLAY PANEL, LIQUID CRYSTAL (F5000)
LCD901 1-805-456-21 DISPLAY PANEL, LIQUID CRYSTAL (FW500)
< DIODE >
LED902 6-500-459-01 LED NSCW505T-ARS (LCD BACK LIGHT)
LED905 6-500-459-01 LED NSCW505T-ARS (LCD BACK LIGHT)
LED907 6-500-510-01 LED CL-195PG-CD-T (DSO) (FW500)
LED907 8-719-053-09 LED SML-310VT-T86 (DSO) (F5000)
LED908 6-500-510-01 LED CL-195PG-CD-T (SOURCE) (FW500)
LED908 8-719-053-09 LED SML-310VT-T86 (SOURCE) (F5000)
LED909 6-500-510-01 LED CL-195PG-CD-T (+) (FW500)
LED909 8-719-053-09 LED SML-310VT-T86 (+) (F5000)
LED910 6-500-510-01 LED CL-195PG-CD-T (LIST CUT) (FW500)
LED910 8-719-053-09 LED SML-310VT-T86 (LIST CUT) (F5000)
LED911 6-500-510-01 LED CL-195PG-CD-T (4) (FW500)
LED911 8-719-053-09 LED SML-310VT-T86 (4) (F5000)
LED912 6-500-510-01 LED CL-195PG-CD-T (5) (FW500)
LED912 8-719-053-09 LED SML-310VT-T86 (5) (F5000)
LED913 6-500-510-01 LED CL-195PG-CD-T (6) (FW500)
LED913 8-719-053-09 LED SML-310VT-T86 (6) (F5000)
LED914 6-500-510-01 LED CL-195PG-CD-T (OFF) (FW500)
LED914 8-719-053-09 LED SML-310VT-T86 (OFF) (F5000)
LED915 6-500-510-01 LED CL-195PG-CD-T (BTM) (FW500)
LED915 8-719-053-09 LED SML-310VT-T86 (BTM) (F5000)
LED916 6-500-510-01 LED CL-195PG-CD-T (1) (FW500)
LED916 8-719-053-09 LED SML-310VT-T86 (1) (F5000)
LED917 6-500-510-01 LED CL-195PG-CD-T (2) (FW500)
LED917 8-719-053-09 LED SML-310VT-T86 (2) (F5000)
LED918 6-500-510-01 LED CL-195PG-CD-T (3) (FW500)
LED918 8-719-053-09 LED SML-310VT-T86 (3) (F5000)
LED919 6-500-510-01 LED CL-195PG-CD-T (> SEEK + M)
(FW500)
LED919 8-719-053-09 LED SML-310VT-T86 (> SEEK + M)
(F5000)
LED920 6-500-510-01 LED CL-195PG-CD-T (> SEEK + M)
(FW500)
LED920 8-719-053-09 LED SML-310VT-T86 (> SEEK + M)
(F5000)
LED921 6-500-510-01 LED CL-195PG-CD-T (DSPL) (FW500)
LED921 8-719-053-09 LED SML-310VT-T86 (DSPL) (F5000)
LED922 6-500-510-01 LED CL-195PG-CD-T (SENS) (FW500)
LED922 8-719-053-09 LED SML-310VT-T86 (SENS) (F5000)
LED923 6-500-510-01 LED CL-195PG-CD-T (MODE) (FW500)
LED923 8-719-053-09 LED SML-310VT-T86 (MODE) (F5000)
LED924 6-500-510-01 LED CL-195PG-CD-T (–) (FW500)
LED924 8-719-053-09 LED SML-310VT-T86 (–) (F5000)
LED925 6-500-510-01 LED CL-195PG-CD-T (. SEEK – m)
(FW500)
LED925 8-719-053-09 LED SML-310VT-T86 (. SEEK – m)
(F5000)
LED926 6-500-510-01 LED CL-195PG-CD-T (. SEEK – m)
(FW500)
LED926 8-719-053-09 LED SML-310VT-T86 (. SEEK – m)
(F5000)
LED927 6-500-510-01 LED CL-195PG-CD-T (EQ3) (FW500)
LED927 8-719-053-09 LED SML-310VT-T86 (EQ3) (F5000)
DISPLAY
